Dec 23, 2022
Touch-screen for easy operation
12.1 inch high resolution color TFT display
USB interfaces support easy software upgrade and data transfer
Compatible with Central Monitoring System(CMS)
Three Working Modes: Monitoring, Surgery and Diagnosis.
Simple and friendly operating display interface.
Multi-display modes suitable for different applications: Standard Interface, Large font,ECG Standard Full Display ,OXY , Trend Table, BP Trend.
Built-in high capacity battery up to 3 hours of continuous work
VGA output for external display
Lead Mode: 5 Leads (1, II, III, AVR, AVL,AVF, V)
Gain: 2.5mm/mV, 5.0mm/mV, 10mm/mV, 20mm/mV
Heart Rate: 15-300 BPM (Adult);15-350 BPM (Neonatal) Resolution: 1 BPM
Sensitivity >200 uV(Peak to peak)
ST measurement range: -2.0 ~+2.0 mV
Accuracy: -0.8mV~+0.8m V:±0.02mV or±10%, which is greater
Other Range: unspecified
Sweep speed: 12.5 mm/s, 25mm/s, 50mm/s
Diagnostic: 0.05~130 Hz
Monitor: 0.5~40 Hz
